Masses
Max. operating mass 4600 kg
Operating mass (incl. ROPS) 3700 kg
Module mass (front/rear) 1855 kg/ 1845 kg
Traction
Speed range 0-9 km/h
Vertical oscillation ±10°
Max. theoretical gradeability 41 %
Engine / Drive
Manufacturer/Model Kubota V2203-M (IIIA)
Type Water cooled diesel engine
Rated power, SAE J199535 kW (48 hp ) @ 2700 rpm
Fuel tank capacity 60 l
Alternative Engine
Manufacturer/Model Kubota V2403-CR E4B (T4)
Type Water cooled diesel engine
Rated power, SAE J199537 kW (50 hp ) @ 2700 rpm
Alternative Engine
Manufacturer/Model Kubota V2403-CR E5B (StageV)
Type Water cooled diesel engine
Rated power, SAE J199537 kW (50 hp ) @ 2700 rpm
Alternative Engine
Manufacturer/Model Kubota V2403-M-DI (CSIV/ ECE R96(IIIA))
Type Water cooled diesel engine
Rated power, SAE J199536.5 kW (48.9 hp) @ 2600 rpm
Alternative Engine
Manufacturer/Model Perkins 403J-E17T (T4/StageV)
Type Water cooled diesel engine
Rated power [engine 5, kW]
Rated power [engine 5, hp]
Rated power [engine 5, rpm]
Rated power, SAE J199536 kW (48 hp) @ 2800 rpm
Hydraulic system
Driving Axial piston pump with variable displacement. Radial piston motors (3) with constant displacement.
Vibration Gear pump/motor with constant displacement.
Service brake Hydrostatic in forward and reverse lever.
Parking/Emergency brake Failsafe multidisc brake in drum and wheel motors.
