Masses
Operating mass (incl. ROPS) 11000 kg
Operating mass (incl. Cab) 11200 kg
Module mass (front/rear) 6500 kg/ 4700 kg
Max. operating mass 11850 kg
Traction
Speed range (Dual/TC/AS) 0 - 12 km/h
Tyre size (8 ply) 23.1 x 26 TR
Max. theoretical gradeability 57 %
Vertical oscillation ±9°
Number of pads 130
Pad area 146 cm2
Pad height 102 mm
Engine / Drive
Manufacturer/Model Cummins QSF3.8 (IV/4final)
Type Water cooled turbo Diesel
Rated power, SAE J199589 kW (120 hp ) @ 2200 rpm
Fuel tank capacity 255 l
DEF tank capacity 20 l
Alternative Engine
Manufacturer/Model Cummins F3.8 (V)
Type Water cooled turbo Diesel
Rated power, SAE J1995100 kW (135 hp) @ 2,200 rpm
Alternative Engine
Manufacturer/Model Cummins QSB4.5 (IIIA/3)
Type Water cooled turbo Diesel
Rated power, SAE J199597 kW (130 hp ) @ 2200 rpm
Hydraulic System
Driving Hydrostatic
Vibration Hydrostatic
Steering Hydrostatic
Service brake Hydrostatic in forward and reverse lever.
Parking/Emergency brake Failsafe multidisc brake in drum gear box and in rear axle.
